SKU: SPS-15-BSP
15mm (1/2" BSP(F)) Stainless Steel Spinner Visual Flow Indicator
15mm (1/2" BSP(F)) Stainless Steel Spinner Visual Flow Indicator
£145.00 ex VAT
✓ In Stock (3 available)
Description
15mm (1/2" BSP(F)) Stainless Steel Spinner
Visual Flow Indicator
16 bar pressure and 200C temperature capability.
Technical Data
Materials :
Body - Stainless Steel (ANC4B) or
- Bronze (LG2)
Clamp Ring - Stainless Steel or Bronze
Spinner - PPS plastic,
‘canary yellow’
Glass Dome - Annealed Borosilicate
‘O’ Ring - Viton
Gasket - Klingersil (C-4400)
Fasteners - Stainless Steel
Pressure : - 16 Bar (maximum working pressure)
Temperature : - 200°C (maximum working temperature)
Connections : - BSP(F) parallel and NPT(F) taper
- Minimum flow rate 1 L/min
- Maximum flow rate 55 L/min
- Maximum Pressure 16 bar
- Maximum Temperature 200°C
